Simplify the complicated EMC measurement and debugging!

The continuous integration and complication of consumer electronics have produced numerous electromagnetic radiation sources. EMC tests can ensure various electronics products’ safety and effectiveness. In order to reduce the development cost and shorten development time, more and more companies are now focusing on EMC planning at the preliminary design phase. In addition to sending products to the lab, they are also looking for or try to establish an EMC solution which is cost effective and test effective diagnosis method.

GW Instek introduces the latest and comprehensive EMC pre-compliance testing solution to meet customers’ requirements of EMC conduction and radiation testing during product development and verification stages. The EMC pre-compliance testing mode is ideal for electronics product development. With this solution, users can resolve problems at the earliest phase to avoid reconfiguration once the product development was finalized. Reducing product development cycles and verification laboratory fees are conducive to expediting the process of product verification and launch time.

For different test categories, GW Instek provides different test packages,

Radiation EMI testing package

- Spectrum Analyzer: GSP-9330

- EMI Near Field Probe Set: GKT-008

- DC Block: ADB-008

- Transient Limiter: GPL-5010

Conduction and radiation EMI testing package

- Spectrum Analyzer: GSP-9330

- EMI Near Field Probe Set: GKT-008

- DC Block: ADB-008

- Two-Line V-Network(LISN): GLN-5040A

- Transient Limiter: GPL-5010

- Isolated Transformer: GIT-5060

Conduction EMI testing package

- Spectrum Analyzer: GSP-9330

- Two-Line V-Network(LISN): GLN-5040A

- Transient Limiter: GPL-5010

- Isolated Transformer: GIT-5060

Radiation EMS testing package

- Spectrum Analyzer: GSP-9330 + Tracking Generator

- EMI Near Field Probe Set: GKT-008

01 gw_product_detail_bar.png GSP-9330 Spectrum Analyzer

02 gw_product_detail_bar.png GKT-008 EMI Near Field Probe Set

03 gw_product_detail_bar.png GLN-5040A Two-Line V-Network(LISN)

04 gw_product_detail_bar.png GIT-5060 isolated transformer

05 gw_product_detail_bar.png GPL-5010 Transient Limiter

点击下载

GSP-9330 spectrum analyzer

Power Cord, Certificate of Calibration, CD-ROM (with User Manual, Programming Manual, SpectrumShot Software, SpectrumShot Quick Start Guide & IVI Driver)

GKT-008 EMI Probe Set

User Manual

GPL-5010 Transient Limiter

User Manual，Warranty Card，Test Report，N(M) to BNC(F)

GLN-5040A Two-Line V-Network(LISN)

User Manual，Adaptor BNC(F) to N-type(M)，Cable BNC(M) to BNC(M)，German Standard Power Adaptor，Warranty Card，Test Report

GIT-5060 Isolated transformer Power Cord, User Manual, Warranty Card

Options

GSP-9330 spectrum analyzer Opt.01 Tracking Generator

Opt.02 Battery Pack

Opt.03 GPIB Interface

ADB-008 DC Block 50ohm，SMA(male)~SMA(female)，0.1MHz-8GHz

Optional Accessories

GSC-009 portable backpack

GRA-415 rack panel

Free Download SpectrumShot Software EMI pretest and remote control software for GSP-9330 (available on GW Instek website)

IVI Driver for GSP-9330 supports LabVIEW/LabWindows/CVI (available on NI website)
